Lindy HDMI 4K60 Audio Extractor
Features
- Extracts stereo or multi-channel audio from an HDMI source
- 4K@60Hz video pass-through with additional support for HDR
- Supports both stereo and multi-channel audio up to 7.1
- CEC and High Bit Rate Audio Pass-through
- 2 year warranty
Specifications
- Video Interface: HDMI
- Interface Standard: 2.0
- Supported Bandwidth: 18Gbps
- Maximum Resolution:
- 3840x2160@60Hz 4:4:4 8bit
- 3840x2160@60Hz 4:2:2 12bit
- HDCP Support: 2.2 / 1.4
- Audio Interface:
- SPDIF
- Analogue L/R
- Chipset: IT66321
- Supported Audio:
- HDMI (Pass-Through): Dolby Digital 2/5.1CH DTS Audio 2/5.1CH Dolby DigitalPlus DTS-HD Master Audio Dolby TrueHD
- Optical: Dolby Digital 2/5.1CH DTS Audio 2/5.1CH DTS Audio 2CH Dolby Digital 2CH
- 3.5mm: Analogue Stereo 2CH
- Maximum Supported Audio Sample Rate: 24-bit/192kHz
- Input Impedance: 1K
- Output Impedance: 10K?
- Output Voltage: 5V 1A
- Frequency Response: <3db; 20h~20kh
- Signal to Noise Ratio: 85db
- Special Features: CEC Pass-through
Connectors
- Input: HDMI Type A (Male)
- Output:
- HDMI Type A (Female)
- SPDIF (Female)
- Analogue L/R (Female)
- USB Micro-B (Female)
- Power: 5.5/2.1mm
Physical Properties
- Dimensions (approx.) WxDxH: 104.4x64x28.3mm (4.11x2.52x1.11in)
- Housing Material: Metal
- Net Weight: 0.118kg (0.26lb)
- Operating Temperature: -5°C - 35°C (23°F - 95°F)
- Storage Temperature: -5°C - 35°C (23°F - 95°F)
- Humidity: 5 - 90% RH (non-condensing)
- Power Requirements: 5VDC 1A
- Colour: Black
Miscellaneous
- Packaging Type: Carton Box
- Packaging Dimensions: 257x56x150mm (10.12x2.2x5.91in)
- Gross Weight: 0.357kg (0.79lb)
- Warranty (Years): 2
- Certificated: CE FCC RoHS REACH & California Proposition 65
